Ganpat Metal supplies alloy steel tubes for industrial equipment, boiler systems, heat exchangers, power generation and mechanical engineering applications. Our range covers ASTM A213 alloy steel grades in different dimensions, lengths and manufacturing forms, subject to the applicable standard and availability. Buyers sourcing molybdenum alloy steel for specified boiler and superheater applications can also enquire about our SA 209 T1 tube range according to their material and dimensional requirements.
Contact Ganpat Metal for alloy steel tube specifications. GM alloy steel tubes are supplied against defined material, dimensional and order requirements. Buyers can enquire about applicable ASTM A213 / ASME SA213 grades, outside diameter, wall thickness, length, end preparation and inspection documentation. The appropriate material specification and delivery condition should be established before ordering, particularly where operating temperature, pressure, mechanical properties or customer-approved standards determine material selection.
Our team can review technical requirements for domestic procurement and export enquiries, helping buyers identify the relevant product specification before quotation.
| Parameter | Specifications |
|---|---|
| Main specification | ASTM A213 / ASME SA213 |
| Other referenced standards | ASTM, ASME and API, according to the applicable product |
| Outside diameter | 1/2 inch to 5 inches; custom diameters subject to confirmation |
| Wall thickness | 0.3 mm to 50 mm, subject to grade, size and manufacturing capability |
| Schedules | SCH 5, SCH 10, SCH 20, SCH 30, SCH 40, SCH 60, SCH 80, SCH 80S, SCH 120, SCH 140, SCH 160, STD, XS and XXS, where applicable |
| Lengths | Single random, double random and required lengths |
| Grades | ASTM A213 T2, T5, T5B, T5C, T9, T11, T12, T22, T23, T91 and T92, subject to availability |
| Manufacturing types | Seamless, ERW, EFW, welded, fabricated and LSAW, where applicable to the specified product |
| End preparation | Plain end, bevelled end and threaded |
| Available forms | Round tubes, square tubes, rectangular tubes, coiled tubes, U-shaped tubes, pancake coils and hydraulic tubes |
Chemical composition varies by grade. The following table reproduces the supplied reference values; these should be verified against the exact grade and specification before being treated as acceptance limits.
| Element | Supplied Reference (%) |
|---|---|
| Carbon (C) | 0.05–0.15 |
| Chromium (Cr) | 1.00–1.50 |
| Manganese (Mn) | 0.30–0.60 |
| Molybdenum (Mo) | 0.44–0.65 |
| Phosphorus (P), maximum | 0.025 |
| Sulphur (S), maximum | 0.025 |
| Silicon (Si) | 0.50–1.00 |
The mechanical properties below are from the supplied reference and must be checked against the applicable grade, product standard and delivery condition. Final acceptance values should be established from the applicable specification and material test documentation rather than applying these figures to every grade in the range.
| Property | Supplied Reference |
|---|---|
| Minimum tensile strength | 415 MPa |
| Minimum yield strength | 205 MPa |
| Minimum elongation | 30% |
| Hardness | As specified by the applicable grade and material standard |
| Grade | Werkstoff No. | UNS | Trade Name / Designation |
|---|---|---|---|
| Alloy Steel T5 | 1.7362 | K41545 | 5Cr-1/2Mo |
| Alloy Steel T9 | 1.7386 | S50400 | 9Cr-1Mo |
| Alloy Steel T11 | 1.7338 | K11597 | 10CrMo5-5 |
| Alloy Steel T12 | 1.7335 | K11562 | 13CrMo4-5 |
| Alloy Steel T22 | 1.7380 | K21590 | 10CrMo9-10 |
| Alloy Steel T91 | 1.4903 | K91560 | X10CrMoVNb9-1 |
Ganpat Metal's alloy steel tube enquiries can cover a range of grades and product specifications according to the intended service and purchasing requirements.
| Grade | Description / Product Page |
|---|---|
| SA209 T1 Tube | View SA209 T1 Tube |
| ASTM A213 T2 | View A213 T2 Tube |
| ASTM A213 T5, T5B, T5C | Available on request |
| ASTM A213 T9, T11, T12 | Available on request |
| ASTM A213 T22, T23 | Available on request |
| ASTM A213 T91, T92 | Available on request |
Ganpat Metal's alloy steel tube enquiries can cover a range of grades and product specifications according to the intended service and purchasing requirements.
For buyers comparing alloy steel tube options, the SA 213 T2 tube range is another relevant specification to review for applicable boiler, superheater and heat-exchanger requirements. Grade selection should be based on the governing standard, design conditions and required mechanical and chemical properties. The listed grades should not be treated as interchangeable.
End Finishes: Plain End, Bevelled End, Threaded End
Outside Diameter Range: 1/2″ to 5″ (custom diameters subject to confirmation)
Wall thickness 0.3 mm to 50 mm according to grade, size and manufacturing capability. Schedules where applicable:
Alloy steel tubes are processed according to the specified grade, dimensions and manufacturing route.
The production process can include material selection according to the specified ASTM grade, seamless or welded production, dimensional control for outside diameter and wall thickness, grade-specific heat treatment, end preparation and final dimensional and material verification.
Inspection scope and documentation should be confirmed when placing the enquiry.
The appropriate grade depends on operating temperature, pressure, design code, corrosion conditions and required mechanical properties.
Ganpat Metal caters to domestic procurement enquiries for alloy steel tubes used in industrial equipment, manufacturing and engineering applications. Buyers can specify the required grade, standard, dimensions, quantity and delivery schedule to receive a quotation based on the confirmed product requirements.
The product range covers ASTM A213 T-grade alloy steel tubes along with SA209 T1 and related specifications. Ganpat Metal holds ISO certification and MSME registration as part of its business and quality credentials.
For pricing and availability, provide the required grade, size, tube type, wall thickness, length, end finish, quantity, testing requirements and delivery location.
Ganpat Metal handles alloy steel tube enquiries for buyers in India and international markets, subject to product availability, order specifications and shipping arrangements.
Markets served and targeted for enquiries:
India
Brazil
New Zealand
Australia
Bangladesh
Malaysia
UAE
Saudi Arabia
Oman
Egypt
Spain
Russia
Kazakhstan
Export enquiries should include the destination country, material grade, applicable standard, dimensions, quantity, packing requirements and required documentation. Delivery schedules and shipping terms are confirmed according to the order.
Send Ganpat Metal your alloy steel tube requirements for a quotation. Include the grade, applicable standard, outside diameter, wall thickness, length, quantity, manufacturing type and inspection requirements. Providing a technical datasheet or purchase specification can help clarify the required product and documentation.
